Input voltage: 2-4S LiPo/2-4S HV LiPo



BEC output: None



Continuous working current of single electric regulator: 13A * 4



External electrical adjustment size: 24 * 25mm (including the maximum size of solder pads and protruding points)



Screw hole pitch 16 * 16MM, hole diameter 3MM



Firmware: BLHELI_ S G_ H_ 30_ 16_ 7. HEX



Supports Dshot600, Dshot300, Dshot150, Oneshot125, Multispot, PWM control signals





Packaging List:



GF16-ESC four in one electrical regulation * 1



M2 * 6.5 shock absorber ball * 8



18AWG wire (red+black) * 2



220UF/25V capacitor * 1



XT30 plug * 1
